Guestbook Application
This tutorial will guide you through building a simple guestbook application using Mycelium. The guestbook allows users to leave a message and to view a list of messages left by others. The application will demonstrate the basics of Mycelium workflows, HTML templating, database access, and project architecture.
If you don't have a preferred Clojure editor already, then it's recommended that you use Calva to follow along with this tutorial.
Installing JDK
Clojure runs on the JVM and requires a copy of JDK to be installed. If you don't have JDK already on your system then OpenJDK is recommended and can be downloaded here. Note that Mycelium requires JDK 11 or greater to work with the default settings. Alternatively, follow the instructions for installing packages on your system.
Installing a Build Tool
Mycelium uses Clojure Deps and CLI for building and running projects.
To install Clojure CLI, follow the steps below depending on your operating system.
MacOS
brew install clojure/tools/clojure
Linux
curl -L -O https://github.com/clojure/brew-install/releases/latest/download/posix-install.sh
chmod +x posix-install.sh
sudo ./posix-install.sh
For both macOS and Linux, you will also need neil to generate new projects:
brew install babashka/brew/neil
Alternatively, you can use deps-new directly.
Creating a new application
Once you have the Clojure CLI installed, you can run the following commands in your terminal to initialize your application:
neil new io.github.mycelium-clj/web yourname/guestbook
cd guestbook
The above will create a new project, named yourname/guestbook, based on the Mycelium web template.
Anatomy of a Mycelium application
The newly created application has the following structure:
guestbook/
├── deps.edn
├── resources/
│ ├── system.edn
│ ├── logback.xml
│ └── html/
│ └── home.html
├── src/clj/yourname/guestbook/
│ ├── core.clj
│ ├── config.clj
│ ├── web/
│ │ ├── handler.clj
│ │ ├── middleware/
│ │ │ └── core.clj
│ │ └── routes/
│ │ └── pages.clj
│ ├── cells/
│ │ └── home.clj
│ └── workflows/
│ └── home.clj
├── env/
│ ├── dev/clj/
│ │ ├── user.clj
│ │ └── yourname/guestbook/
│ │ ├── env.clj
│ │ └── dev_middleware.clj
│ └── prod/clj/
│ └── yourname/guestbook/
│ └── env.clj
└── test/clj/yourname/guestbook/
└── core_test.clj
Let's take a look at what the files in the root folder of the application do:
deps.edn- used to manage the project configuration and dependenciesresources/system.edn- used for system configuration with Integrant and Aero.gitignore- a list of assets, such as build-generated files, to exclude from Git
The Source Directory
All our code lives under the src/clj folder. Since our application is called yourname/guestbook, this is the root namespace for the project. Let's take a look at all the namespaces that have been created for us.
guestbook
config.clj- this is the place where yoursystem.ednis read in to create an Integrant configuration mapcore.clj- this is the entry point for the application that contains the logic for starting and stopping the server
guestbook.web
The web namespace is used to define the edges of your application that deal with server communication, such as receiving HTTP requests and returning responses.
handler.clj- defines the Ring handler and router configurationmiddleware/core.clj- an aggregate of default middleware and environment-specific middlewareroutes/pages.clj- HTTP routes wired to Mycelium workflows
guestbook.cells
The cells namespace is where Mycelium cell definitions live. Cells are functions with explicit input/output schemas. You can think of them as being akin to microservices. Each one accepts resources and a state map, then returns a new state that propagates in the workflow. These functions can do IO and produce side effects.
home.clj- cell definitions for the default home page
guestbook.workflows
The workflows namespace is where Mycelium workflow definitions live. Workflows compose cells into directed graphs.
home.clj- the home page workflow (a pipeline of cells)
Understanding Cells and Workflows
Mycelium applications are built from two core concepts:
Cells represent individual steps in a workflow, similar to microservices. Each cell can do IO and produce side effects, and the state it returns is used by the workflow engine to decide which cell to run next. Cells have explicit input/output schemas and are registered via defmethod, receiving a resources map and a data map:
(defmethod cell/cell-spec :request/parse-home [_]
{:id :request/parse-home
:doc "Extract name parameter from the HTTP request"
:handler (fn [_resources data]
(let [params (get-in data [:http-request :query-params])
name (or (get params "name") "World")]
(assoc data :name name)))
:schema {:input [:map [:http-request :map]]
:output [:map [:name :string]]}})
The :schema map declares what data the cell expects (:input) and what it produces (:output). These schemas use Malli and are validated at compile time.
Workflows compose cells into directed graphs. The simplest form is a :pipeline:
(def workflow-def
{:cells {:start :request/parse-home
:render :page/render-home}
:pipeline [:start :render]})
(def compiled (myc/pre-compile workflow-def))
Data accumulates through the pipeline — each cell receives all keys from prior cells plus the initial input. The workflow is pre-compiled at load time for optimal performance.
Compiled workflows are wired to HTTP routes using mycelium.middleware/workflow-handler:
(mw/workflow-handler home/compiled {})
The handler passes the Ring request as {:http-request request} and extracts the :html key from the result as the response body.
The Env Directory
Environment-specific code and resources are located under the env/dev and env/prod paths. The dev configuration will be used during development and testing, while the prod configuration will be used when the application is packaged for production.
The Dev Directory
user.clj- a utility namespace for REPL development. You start and stop your server from here during development.guestbook/env.clj- contains the development configuration defaultsguestbook/dev_middleware.clj- contains middleware used for development that should not be compiled in production
The Prod Directory
guestbook/env.cljnamespace with the production configuration
The Test Directory
Here is where we put tests for our application. Some test utilities have been provided.
The Resources Directory
This is where we put all the resources that will be packaged with our application. The system.edn file defines the system configuration, and the html directory contains Selmer templates.
Starting Our Server
Your REPL is your best friend in Clojure. Let's start our local development REPL by running
clj -M:dev
Once you are in the REPL, you can start the system:
(go) ;; Start the system
(halt) ;; Stop the system
(reset) ;; Reload code and restart
To confirm that your server is running, visit http://localhost:3000.
System Configuration
System resources such as HTTP server ports and database connections are defined in the resources/system.edn file. For example, this key defines HTTP server configuration:
:server/http
{:port #long #or [#env PORT 3000]
:host #or [#env HTTP_HOST "0.0.0.0"]
:handler #ig/ref :handler/ring}
Components are wired together using Integrant references (#ig/ref). The dependency chain is: server → handler → router → routes.
Now that we've looked at the structure of the default project, let's add the guestbook functionality.
Adding Database Support
Our guestbook needs a database to store messages. We'll use SQLite with next.jdbc.
First, add the database dependencies to your deps.edn under the :deps key:
com.github.seancorfield/next.jdbc {:mvn/version "1.3.939"}
org.xerial/sqlite-jdbc {:mvn/version "3.45.3.0"}
Next, create a database namespace at src/clj/yourname/guestbook/db.clj:
(ns yourname.guestbook.db
(:require [integrant.core :as ig]
[next.jdbc :as jdbc]))
(defmethod ig/init-key :db/connection [_ {:keys [jdbc-url]}]
(let [ds (jdbc/get-datasource {:jdbcUrl jdbc-url})]
(jdbc/execute! ds
["CREATE TABLE IF NOT EXISTS guestbook
(id INTEGER PRIMARY KEY AUTOINCREMENT,
name VARCHAR(30),
message VARCHAR(200),
timestamp TIMESTAMP DEFAULT CURRENT_TIMESTAMP)"])
ds))
This creates an Integrant component that provides a database connection and ensures the guestbook table exists on startup.
Now add the database configuration to resources/system.edn:
:db/connection
{:jdbc-url #profile {:dev "jdbc:sqlite:guestbook_dev.db"
:test "jdbc:sqlite:guestbook_test.db"
:prod #or [#env JDBC_URL "jdbc:sqlite:guestbook.db"]}}
Update the :reitit.routes/pages entry to reference the database:
:reitit.routes/pages
{:db #ig/ref :db/connection}
Finally, require the db namespace in core.clj so the Integrant key is registered:
(ns yourname.guestbook.core
(:require
...
[yourname.guestbook.db]))
Creating Guestbook Cells
Now let's define the cells for our guestbook. Create a new file at src/clj/yourname/guestbook/cells/guestbook.clj:
(ns yourname.guestbook.cells.guestbook
(:require [mycelium.cell :as cell]
[next.jdbc :as jdbc]
[next.jdbc.result-set :as rs]
[selmer.parser :as selmer]))
(defmethod cell/cell-spec :guestbook/load-messages [_]
{:id :guestbook/load-messages
:doc "Load all guestbook messages from the database"
:requires [:db]
:handler (fn [{:keys [db]} data]
(assoc data :messages
(jdbc/execute! db
["SELECT * FROM guestbook ORDER BY timestamp DESC"]
{:builder-fn rs/as-unqualified-maps})))
:schema {:input [:map]
:output [:map [:messages [:sequential :map]]]}})
(defmethod cell/cell-spec :page/render-guestbook [_]
{:id :page/render-guestbook
:doc "Render the guestbook page with messages"
:handler (fn [_resources data]
(assoc data :html
(selmer/render-file "html/guestbook.html"
{:messages (:messages data)})))
:schema {:input [:map [:messages [:sequential :map]]]
:output [:map [:html :string]]}})
The :guestbook/load-messages cell declares :requires [:db], which means it expects a :db key in its resources map. We use rs/as-unqualified-maps so that result columns are returned as simple keys like :name and :message rather than qualified keys like :guestbook/name.
The :page/render-guestbook cell takes the loaded messages and renders a Selmer template.
Creating the Guestbook Workflow
Create the workflow at src/clj/yourname/guestbook/workflows/guestbook.clj:
(ns yourname.guestbook.workflows.guestbook
(:require [mycelium.core :as myc]
;; Load cell definitions
[yourname.guestbook.cells.guestbook]))
(def home-def
{:cells {:start :guestbook/load-messages
:render :page/render-guestbook}
:pipeline [:start :render]})
(def home-compiled (myc/pre-compile home-def))
This defines a simple pipeline: load messages from the database, then render the page. Note that the first cell in a pipeline must be named :start — this is how Mycelium determines the entry point. The workflow is pre-compiled at namespace load time for optimal performance.
Adding Routes
Update src/clj/yourname/guestbook/web/routes/pages.clj to add our guestbook routes:
(ns yourname.guestbook.web.routes.pages
(:require [integrant.core :as ig]
[mycelium.middleware :as mw]
[next.jdbc :as jdbc]
[yourname.guestbook.workflows.guestbook :as guestbook]))
(defn save-message-handler [db]
(fn [{:keys [params]}]
(let [{:keys [name message]} params]
(when (and (seq name) (seq message))
(jdbc/execute! db
["INSERT INTO guestbook (name, message) VALUES (?, ?)"
name message])))
{:status 302
:headers {"Location" "/"}
:body ""}))
(defn page-routes [{:keys [db]}]
[["/" {:get {:handler (mw/workflow-handler
guestbook/home-compiled
{:resources {:db db}})}}]
["/save-message" {:post {:handler (save-message-handler db)}}]])
(derive :reitit.routes/pages :reitit/routes)
(defmethod ig/init-key :reitit.routes/pages
[_ opts]
(fn []
["" (page-routes opts)]))
The home page route uses mw/workflow-handler to wire the compiled workflow to the GET endpoint. The workflow handler automatically passes the Ring request as {:http-request request} and extracts the :html key from the workflow result as the response body. Resources (in this case, the database connection) are passed through the options map.
The save route uses a simple handler function that extracts the form parameters, saves the message to the database, and redirects back to the home page. We use HTML5 required attributes on the form inputs for client-side validation.
Creating the HTML Template
Create resources/html/guestbook.html:
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>Guestbook</title>
<link rel="stylesheet"
href="https://cdn.jsdelivr.net/npm/bulma@0.9.4/css/bulma.min.css">
<style>
ul.messages { list-style: none; }
ul.messages li {
padding: 10px;
border-bottom: 1px dotted #ccc;
}
li:last-child { border-bottom: none; }
li time { font-size: 12px; color: #888; }
form { padding: 30px; }
</style>
</head>
<body>
<section class="section">
<div class="container">
<h1 class="title">Guestbook</h1>
<div class="columns">
<div class="column">
<h3 class="subtitle">Messages</h3>
<ul class="messages">
{% for item in messages %}
<li>
<time>{{item.timestamp}}</time>
<p>{{item.message}}</p>
<p><strong>- {{item.name}}</strong></p>
</li>
{% endfor %}
</ul>
</div>
</div>
<div class="columns">
<div class="column">
<form method="POST" action="/save-message">
<div class="field">
<label class="label">Name</label>
<div class="control">
<input class="input" type="text"
name="name" required />
</div>
</div>
<div class="field">
<label class="label">Message</label>
<div class="control">
<textarea class="textarea"
name="message" required></textarea>
</div>
</div>
<div class="field">
<div class="control">
<input type="submit"
class="button is-primary"
value="Submit" />
</div>
</div>
</form>
</div>
</div>
</div>
</section>
</body>
</html>
We use a for iterator to walk through the messages. Since each message is a map with :name, :message, and :timestamp keys, we can access them by name in the Selmer template.
The form uses HTML5 required attributes for client-side validation, and submits a POST request to /save-message.
Testing the Application
Restart your REPL to pick up the new dependencies and code:
(reset)
Visit http://localhost:3000 and try adding some messages!
You can also test the database from the REPL:
(require '[next.jdbc :as jdbc])
(require '[next.jdbc.result-set :as rs])
(def db (:db/connection integrant.repl.state/system))
(jdbc/execute! db
["INSERT INTO guestbook (name, message) VALUES (?, ?)"
"REPL User" "Hello from the REPL!"])
(jdbc/execute! db
["SELECT * FROM guestbook"]
{:builder-fn rs/as-unqualified-maps})
Adding some tests
Create a test at test/clj/yourname/guestbook/guestbook_test.clj:
(ns yourname.guestbook.guestbook-test
(:require [clojure.test :refer :all]
[next.jdbc :as jdbc]
[next.jdbc.result-set :as rs]
[mycelium.core :as myc]
[yourname.guestbook.cells.guestbook]
[yourname.guestbook.workflows.guestbook :as guestbook])
(:import [java.io File]))
(defn test-db []
(let [tmp (File/createTempFile "guestbook-test" ".db")
path (.getAbsolutePath tmp)
ds (jdbc/get-datasource {:jdbcUrl (str "jdbc:sqlite:" path)})]
(.deleteOnExit tmp)
(jdbc/execute! ds
["CREATE TABLE IF NOT EXISTS guestbook
(id INTEGER PRIMARY KEY AUTOINCREMENT,
name VARCHAR(30),
message VARCHAR(200),
timestamp TIMESTAMP DEFAULT CURRENT_TIMESTAMP)"])
ds))
(deftest test-home-workflow
(let [ds (test-db)
_ (jdbc/execute! ds
["INSERT INTO guestbook (name, message) VALUES (?, ?)"
"Test User" "Hello World"])
result (myc/run-compiled
guestbook/home-compiled
{:db ds}
{})]
(is (= 1 (count (:messages result))))
(is (= "Test User" (:name (first (:messages result)))))
(is (string? (:html result)))))
Run tests with:
clj -M:test
Packaging the application
You can run the application directly using:
clj -M:run
For building a standalone JAR for deployment, you can add tools.build to your project. Create a build.clj at the project root:
(ns build
(:require [clojure.tools.build.api :as b]))
(def lib 'yourname/guestbook)
(def class-dir "target/classes")
(def basis (delay (b/create-basis {:project "deps.edn"})))
(def uber-file "target/guestbook-standalone.jar")
(defn clean [_]
(b/delete {:path "target"}))
(defn uber [_]
(clean nil)
(b/copy-dir {:src-dirs ["src/clj" "resources" "env/prod/clj"]
:target-dir class-dir})
(b/compile-clj {:basis @basis
:src-dirs ["src/clj" "env/prod/clj"]
:class-dir class-dir})
(b/uber {:class-dir class-dir
:uber-file uber-file
:basis @basis
:main 'yourname.guestbook.core}))
Add a :build alias to deps.edn:
:build {:deps {io.github.clojure/tools.build
{:git/tag "v0.10.5" :git/sha "2a21b7a"}}
:ns-default build}
Then build and run:
clj -T:build uber
java -jar target/guestbook-standalone.jar
By default, the production build uses jdbc:sqlite:guestbook.db. You can override this by setting the JDBC_URL environment variable.
The complete working source for this tutorial is available in the guestbook example. The base project template used to generate new projects is in the mycelium-web-template repository.
